Drive Ultra Light Plus, Hi/Lo Semi Electric Bed
Description
- Large glow in the dark hand pendant has easy-to-use controls for adjusting head and foot deck sections to comfortable positions; built in battery backup and power indicator light. (Figure A)
- In the event of a power failure, a 9 volt battery (not included) located in the hand pendant can lower the head and foot sections to a horizontal position. No crank needed.
- Hand Crank adjustable bed height is easy-to-raise and lower for comfort and accessibility. (Figure B)
- 15570FR comes complete with full side rails and frame mounted retractable receiver bracket to eliminate cross braces, ensure proper placement and reduce loss. (Figure C)
- Ultra-light head and foot frame weigh only 42 lbs. each. (Figure D)
- Slat Deck provides strength, no-sag mattress support, no links to connect, easy-to-clean
- Channel frame construction provides excellent strength and reduced weight.
- Frame safety lock slides over hanger pins to prevent disengaging from bed ends.
- Self-contained motor for reduced weight and noise (same as Delta™ Ultra-Light 1000).
- UL approved Motor can be installed and removed with patient in bed. (Figure E)
- Molded Plastic Bed end panels are durable, lightweight and attractive to blend with décor. (Figure F)
- Headboard is taller than footboard to better fit home décor; head and foot boards are interchangeable.
- Casters are standard.
- Bed ships in two cartons for ease of handling, delivery and setup.
- Weight Capacity 450 lbs. evenly distributed. Includes occupant, mattress, side rails, trapeze, accessories, personal affects, etc.
- Optional trapeze available (model #15560TRAPEZE)
- Item # 15570HR bed comes complete with clamp-on style half rails in place of full rails. (Figure G)
Specifications
Specifications
| Bed Height w/3″ Casters | Low Height 14 3/4″ | Hi Hgt 22″ |
|---|---|
| Unit Dimensions | 35″ (W) x 84″ (L) |
| Weight | 163 lbs. (74 kg) |
| Carton Shipping Weight | 176 lbs. (80 kg) |
| Weight Limit | 450 lbs. (Includes occupant, mattress, side rails, trapeze, accessories, personal affects, etc.) |
| Warranty | (Original Purchaser) 5 Years on Motor and Hand Control, Limited Lifetime on Welds and Frame, 1 Year on All Other Parts and Components |
Downloads
Downloads
Owners Manual
Catalog Page
Clinical Info
Products
Products
| Item # | Product Description | HCPCS Code Definition | HCPCS* | UOM | |
|---|---|---|---|---|---|
| 15570 | Select | Semi-Electric Hi/Lo | Hospital Bed, Semi-Electric (Head and Foot Adjustment), Without Side Railes, WIthout Mattress | E0295 | 1/cs |
| 15570FR | Select | Semi-Electric Hi/Lo Bed with Full Side Rails | Hospital Bed, Semi-Electric (Head and Foot Adjustment), WIth Any Type Side Rails, Without Mattress | E0261 | 1/cs |
| 15570FR-PKG | Select | Semi-Electric Hi/Lo Bed with Full Side Railes and Mattress (Item #15006) | Hospital Bed, Semi-Electric (Head and Foot Adjustment), WIth Any Type Side Rails, With Mattress | E0260 | 1/cs |
| 15570HR | Select | Semi-Electric Hi/Lo Bed with Half Side Rails | Hospital Bed, Semi-Electric (Head and Foot Adjustment), WIth Any Type Side Rails, Without Mattress | E0261 | 1/cs |
| 15570HR-PKG | Select | Semi-Electric Hi/Lo Bed with Half Side Rails and mattress (Item #15006) | Hospital Bed, Semi-Electric (Head and Foot Adjustment), WIth Any Type Side Rails, With Mattress | E0260 | 1/cs |
