Competitor™ Semi-Electric Bed
Product Summary
- Adjustable-height bed, deck height is adjustable without tools.
- Complete with full side rails and frame mounted retractable receiver bracket to eliminate cross braces and ensure proper placement to reduce loss
- Large glow in the dark hand pendant has easy-to-use controls, built in battery backup and troubleshooting light.
- Ultra-compact single carton (36″ x 9″ x 45″) for easy handling.
- Safety lock slides over hanger pins to prevent disengaging.
- Self-contained motor for reduced weight and noise (same as Delta™ Ultra Light 1000).
- UL approved Motor can be installed and removed with patient in bed.
- Casters are an option.
- Head and foot frame weigh only 42 lbs. each.
- Head and foot boards are interchangeable.
- Optional trapeze available (model #15560TRAPEZE)
Specifications
Specifications
| Bed Height Minimum Without Casters | 11″ – 20″ |
|---|---|
| Bed Height Maximum With Casters | 14″ – 23″ |
| Unit Dimensions | 35″ (W) x 84″ (L) |
| Weight | 143 lbs. |
| Carton Shipping Weight | 151 lbs. |
| User Weight Limit | 450 lbs Maximum weight limit includes weight of occupant, all accessories such as mattress, side/assist rails, trapeze, any personal affects, etc. |
| Warranty | (Original Purchaser) 5 Years on Motor and Hand Control, Limited Lifetime on Welds and Frame, 1 Year on All Other Parts and Components |
Downloads
Downloads
Owners Manual
Catalog Page
Parts Diagram
Products
Products
| Item # | Product Description | HCPCS* | UOM | |
|---|---|---|---|---|
| 15560 | Select | Semi-Electric Bed with Full Side Rails | E0261 | 1/cs |
| 15560-PKG | Select | Semi-Electric Bed with Full Side Rails and Mattress (item #15006) | E0260 | 1/cs |
| 15560-HR | Select | Semi-Electric Bed with Half Rails | E0261 | 1/cs |
| 15560-HR-PKG | Select | Semi-Electric Bed with Half Rails and Mattress (Item #15006) | 1/cs |
Parts
Parts
| Diagram Number | Part Description | Part Number | |
|---|---|---|---|
| 1 | Select | Head or Foot Board | 15560-01 |
| 1 | Select | Fabric Cover Set Head & Foot Board | 15560-24 |
| 2 | Select | Head Section | 15560-02N |
| 3 | Select | Foot Section | 15560-03 |
| 4 | Select | Full Length Side Rails Complete | 15560-04 |
| 4a | Select | Half Rails | 15560-25 |
| 5 | Select | Plastic Bed End Panel | 15560-05 |
| 6 | Select | Leg with Tip | 15560-06 |
| 7 | Select | Leg Tip | 15560-07 |
| 7 | Select | Caster Set | 15044CSET |
| 8 | Select | Magnetic Leg Stud Cover | 15560-08 |
| 9 | Select | Side Rail Receiver Left, Right | 15560-09 |
| 10 | Select | Foot Actuator Bar | 15560-10 |
| 11 | Select | Head Actuator Bar | 15560-11 |
| 12 | Select | Frame Fastener Clip & Strap | 15560-12 |
| 13 | Select | Z Bar for Foot Frame | 15560-13 |
| 14 | Select | Frame Connector Release Knob | 15560-14 |
| 15 | Select | Mattress Stop | 15560-15 |
| 16 | Select | Full Length side Rail Release Knob | 15560-16 |
| 17 | Select | Full Length Side Rail Receiver Locking Nut | 15560-17 |
| 18 | Select | Leg Height Adjustment Lever | 15560-18 |
| 19 | Select | Rubber Frame Stopper | 15560-19 |
| 20 | Select | Square End Cap | 15560-20 |
| 21 | Select | Hand Control | 1503HC-G |
| 22 | Select | Motor | 15038MO |
