Med Aire Low Air Loss Mattress Replacement System with Alarm
Features
- 3-Air cells remain static to enhance patient comfort
- 8 – LPM (Liters per Minute) pump produces consistent air flow
- 8″ cells are constructed with Nylon/TPU that is soft and lightweight
- CPR valves provide fast (20-Second) deflation
- Cell-on-Cell design prevents the patient from “Bottoming Out” in the event of a power failure
- Easy to replace individual bladders
- Ideal for use in hospitals, nursing homes and home care
- LED and Audible alarm activate when pressure falls below 10 mmHg
- Mattress has 20 air bladders, 9 with laser hose to achieve low air los function helping to keep the patient cool and speed recovery
- Mattress operates in an alternating pressure mode
- The product is designed to be used in the prevention, treatment and management of Pressure Ulcers
- The zippered Nylon TPU cover material is water resistant, vapor permeable and quilted
Description
The Med-Aire Low Air Loss Alternating Pressure Mattress Replacement System by Drive Medical is designed to be used in the prevention, treatment and management of Pressure Ulcers. The mattress operates in an alternating pressure mode and is ideal for use in hospitals, nursing homes and home care. The individuals bladders are easy to remove and replace and the 3-Air cells remain static to enhance patient comfort. LED and Audible alarms activate when the pressure falls below 10 mmHg. and the Cell-on-Cell design prevents the patient from “Bottoming Out” in the event of a power failure, ensuring their safety and comfort. The 8 – LPM (Liters per Minute) pump produces consistent air flow. This mattress has 20 air bladders, 9 with laser hose to achieve low air loss function helping to keep the patient cool and speed recovery. The 8″ cells are constructed with Nylon/TPU that is soft and lightweight, providing comfort to all users. The zippered Nylon TPU cover material is water resistant, vapor permeable and quilted, making it ideal for hospital use. The CPR valves provide fast (20-Second) deflation.
Specifications
Specifications
| Control Unit Airflow | 8 LPM |
|---|---|
| Control Unit Cycle Time | 10, 15, 20, 25 Minutes |
| Control Unit Type | Compressor |
| Control Unit Alarms | Visual / Audible |
| Mattress Cover Material | Fluid-Resistant Stretch |
| Weight Capacity | 450 lbs. |
| Warranty | 18 Month Limited |
Downloads
Downloads
Owners Manual
Catalog Page
Parts Diagram
Clinical Info
Products
Products
| Item # | Product Description | Product Dimensions | UOM |
|---|---|---|---|
| 14029 | Alternating Pressure/Low Air Loss Mattress System | 36″ (W) X 80″ (L) X 8″ (H) | 1/ea |
| 14029-84 | Alternating Pressure/Low Air Loss Mattress System | 36″ (W) X 84″ (L) X 8″ (H) | 1/ea |
Parts
Parts
| Diagram Number | Part Description | Part Number |
|---|---|---|
| 14029MN | ||
| 14029C | ||
| 14029-base | ||
| 14029-CELL | ||
| 14029-cell1 | ||
| 14001-l | ||
| 14001-t | ||
| 14029-fftc | ||
| 14029-fmtc | ||
| 14028v | ||
| 14013 | ||
| 14028t | ||
| 14029XP | ||
| 14030xp-s | ||
| 14007-3port | ||
| 14007or-3 | ||
| 14030hk | ||
| 14029fn | ||
| 14029xp-fc | ||
| 14530f | ||
| Power cord | 15005PC | |
| 14029b |
